2.00mm Pitch Wire To Board Connectors series product

2.00mm Pitch Wire To Board ConnectorsZOOKE2000 SPECIFICATIONS Current rating：2A AC/DC Voltage rating：250V AC/DC Withstanding voltage：800V AC/miuute. Contact resistance：20MΩ Max. Insulation resistance：1000MΩ Min. Temperature range：-40℃~+105℃ Wire range：AWG 22#~28#     Item Material Pin QTY Housing PA66 UL94V-0 02~16 1000Pcs/Bag Wafer LCP UL94V-0 02~16 1000Pcs/Reel Terminal Phosphor Bronze - 10,000Pcs/Reel Wire to board connectors with a 2.0mm pitch have become increasingly popular in the electronics industry due to their compact size and high reliability. A wire to board connector is a type of electrical connector that allows for the connection of wires to a printed circuit board (PCB). These connectors are commonly used in applications where a durable and secure connection between wires and the PCB is required.   The 2.0mm pitch refers to the distance between each pin or contact in the connector. A smaller pitch allows for more contacts to…
