Ultrafine pepper grinder mill

CWF Series Fine Powder Pulverizer Brief： l   Mainly applied by pharmacy, foodstuff and chemical industry etc. l   GMP design; suitable to large, medium or small batch production. l   Machine is made with stainless steel without sieve and different output size is obtained by adjusting grading motor. Ingredients are fed into hopper and conveyed via feeding motor to the pulverizing room, then smashed by high-speed rotating blades; then, the smashed ingredients are pulled into cyclone segregator by the overpressure generated from blower, discharged from the rotary valve while dust collected into filter bags in pulse dust collector box. There is no fugitive dust during production to make better use of the materials and save cost. Technical Specifications:   Model CWF15 CWF20 CWF30 CWF60 Capacity (kg/h) 30-120 50-230 80-300 150-800  Speed(r/min) 5200 4800 3800 2900 Power（KW） 19.82 21 46 83.8 Output Size(mesh) 6…
